2SA114

Type Designator: 2SA114

Material of Transistor: Ge

Polarity: PNP

Maximum Collector Power Dissipation (Pc): 0.05 W

Maximum Collector-Base Voltage |Vcb|: 34 V

Maximum Emitter-Base Voltage |Veb|: 6 V

Maximum Collector Current |Ic max|: 0.01 A

Max. Operating Junction Temperature (Tj): 85 °C

Transition Frequency (ft): 10 MHz

Collector Capacitance (Cc): 12 pF

Forward Current Transfer Ratio (hFE), MIN: 40

Noise Figure, dB: -
