2SA1242

Type Designator: 2SA1242

Material of Transistor: Si

Polarity: PNP

Maximum Collector Power Dissipation (Pc): 1 W

Maximum Collector-Base Voltage |Vcb|: 35 V

Maximum Collector-Emitter Voltage |Vce|: 20 V

Maximum Emitter-Base Voltage |Veb|: 8 V

Maximum Collector Current |Ic max|: 5 A

Max. Operating Junction Temperature (Tj): 120 °C

Transition Frequency (ft): 100 MHz

Collector Capacitance (Cc): 62 pF

Forward Current Transfer Ratio (hFE), MIN: 100

Noise Figure, dB: -
