2SA1727

Type Designator: 2SA1727

Material of Transistor: Si

Polarity: PNP

Maximum Collector Power Dissipation (Pc): 10 W

Maximum Collector-Base Voltage |Vcb|: 400 V

Maximum Collector-Emitter Voltage |Vce|: 400 V

Maximum Collector Current |Ic max|: 0.1 A

Max. Operating Junction Temperature (Tj): 175 °C

Forward Current Transfer Ratio (hFE), MIN: 280

Noise Figure, dB: -

Package: TO236
