2SB750

Type Designator: 2SB750

Material of Transistor: Si

Polarity: PNP

Maximum Collector Power Dissipation (Pc): 35 W

Maximum Collector-Base Voltage |Vcb|: 60 V

Maximum Collector-Emitter Voltage |Vce|: 60 V

Maximum Emitter-Base Voltage |Veb|: 5 V

Maximum Collector Current |Ic max|: 2 A

Max. Operating Junction Temperature (Tj): 160 °C

Forward Current Transfer Ratio (hFE), MIN: 5000

Noise Figure, dB: -
