2SB825

Type Designator: 2SB825

Material of Transistor: Si

Polarity: PNP

Maximum Collector Power Dissipation (Pc): 40 W

Maximum Collector-Base Voltage |Vcb|: 60 V

Maximum Collector-Emitter Voltage |Vce|: 60 V

Maximum Emitter-Base Voltage |Veb|: 6 V

Maximum Collector Current |Ic max|: 7 A

Max. Operating Junction Temperature (Tj): 150 °C

Transition Frequency (ft): 5 MHz

Forward Current Transfer Ratio (hFE), MIN: 70

Noise Figure, dB: -
